| Size Range | 15A~80A (1/2”~3”) |
| Max. Pressure | 15kg/cm2 (210PSI) |
| Max. Rotation Speed | 15A~25A (1/2”~1”) : 300RPM |
| 32A~80A (1.1/4”~3”) : 150RPM | |
| Max. Temperature | 220°C (420°F) |
| Media | Hot Oil |
| * Avoid max. Pressure at max. rpm operation | |
3200 Series Rotary Joints
| Features |
| Spherical Sealing |
| Two Widely-Spaced Carbon Bearing |
| Self-supported & Alignment rotating union Easily field repairable |
| For Hot Oil media |
| Over Max.Temp.(220°C/420°F), consult Fitting House |
