3000 series Rotary Joints

Features

– Spherical Sealing

– Two Widely-Spaced Carbon Bearing

– Self-supported & Alignment rotating union

– Easily field repairable

– For Steam media

– Non-Lubrication type

Size Range	15A~80A (1/2”~3”)
Max. Pressure	15kg/cm2 (210PSI)
Max. Rotation Speed	15A~25A (1/2”~1”) : 300RPM
	32A~80A (1.1/4”~3”) : 150RPM
Max. Temperature	220°C (420°F)
Media	Steam
* Avoid max. Pressure at max. rpm operation
