6000 Series Rotary Joints

Features

– For Low Speed rotation with Air/Oil Pressure

Model : FTBR6011-10A, FTBR6011-15A, FTBR6011-20A
Max. Air Pressure	10kg/cm2 (150PSI)
Max. Hydraulic Pressure	210kg/cm2 (3000PSI
Max. Rotation Speed	250RPM
Max. Temperature	100°C (210°F)
Media	Air, Hydraulic Oil
* Avoid max. Pressure at max. rpm operation
